B-200 Van Refrigeration Unit

Model: B-150/150C
Driven Type : Electric Battery Powered
Cooling Capacity: 0℃/+30℃ 2000W - 18℃/+30℃ 950W
Application: 2-6m³
Refrigerant: R404a ,0.8-0.9kg

We're here to help: Easy ways to get the answers you need.

Van Refrigeration Unit

HOT PRODUCTS

Brief Introduction of B-150/150C Small Van Refrigeration Units


If you are looking for a solution to convert into a refrigerated vans, then our B-150/150C electric van refrigeration is a good choice for this conversion. It is DC powered 12V/24V voltage for small cargo vans with 2-6m³ van box. For temperature range, we have two solution, B-150 electric van refrigeration is for -18℃ ~ +25℃ temperature controlled and B-150C refrigeration units for small vans is for - 5℃ ~ +25℃ temperature controlled.

The most advantages of this small van refrigeration units is that the easy to install. The compressor is inner side of condenser, so this integrated design make it more convenient to install. Besides that, it need DC 12V/24V voltage, which is directly connecting with van battery for cooling. We also have the optional choice for electric standby system to make the refrigeration units for small vans working all time. The electric standby system is AC110V-240V voltage.

B-200 Electric Van Refrigeration Unit - KingClima


Features of B-150/150C Small Van Refrigeration Units


◆ Driven by DC powered vehicle battery,save much fuel.
◆ Add CPR valve to protect compressors, suitable for the hot place.
◆ Realize that vehicle engine is off but cooling system is continuous.
◆ Adopt Eco-friendly refrigerant: R404a
◆ Hot gas defrosting system: Auto and manual for choices
◆ Worldwide famous key parts: Sanden compressor, Danfoss Valve, Good Year, Spal fans; Codan, etc.
◆ Compressor is in the inner side of condenser, helps save installation space and easy to install.


Technical

Technical Data of B-150/150C Electric Van Refrigeration


Model B- 150/150C
Temperature Range In Container - 18℃ ~ +25℃/ - 5℃ ~ +25℃
Cooling Capacity 0℃/+30℃ 2000W
- 18℃/+30℃ 950W
Compressor Model DC,25cc/r
Air volume 910m³/h

Condenser
Coil Aluminum micro-channel parallel flow coils
Fan 1 Axial Fan, 1300m3/h
Dimensions &Weight 865x660x210 mm

Evaporator
Coil Aluminum foil with internal ridge copper tube
Fan 1 Axial Fans,800m3/h
Dimensions &Weight 610×550×175mm
Refrigerant R404a ,0.8-0.9kg
Application 2-6m³
Optional Function Electric standby, Heating
